SMD: | 2835 |
Led/m: | 120 |
Power: | 12w |
Voltage: | 12V |
Color: | Cold white |
|
Product parameters:
Item No |
AB2835CW120-12V |
Led type |
Smd 2835 |
Led source |
Sanan/ epistar |
Material |
Aluminum |
Input voltage |
12v/24v |
Power |
9.6w/m |
Led Qty/ (M): |
60 |
Lumen |
10-12lm/led |
Dimension |
8*5000mm |
Emitting Color: |
Cool white |
Viewing Angle |
120 |
Back tape |
3M adhesive |
IP degree |
IP20 |
Life time(hour) |
50000 hours |
Certificates |
CE & Rohs |
Warranty |
2 years warranty |
Warranty |
2 years |
Working temp |
-20 - 60 |
Back tape |
3M adhesive |
Packing |
100rolls/carton |
Color temperature:
Warm white: 2800-3200K;
Nature White:4000-4500K;
White:6000-7000K;
Cool White: >7000K
Red/Blue/Green/Yellow/ RGB
IP degree:
IP20/33 (Bare
Board) Using when indoor and keep away from rain wet
IP65 (Epoxy) fit on damp location (bathroom,
kitchen and corridor)
IP67 (Casing pipe) fit on outdoor exterior
building
IP68 (Silicone tube encapsulation) can be work
underwater
Product
features:
1. Strong flexibility: curve or bent as any angle that need;
2. Stable & High quality lighting: High quality SMD5050chips; with high brightness, large emitting angle, low thermal resistance, and low light decay, high uniformity of the emitting color;
3.Flexible & slim form, cut table at every 3LEDs ; convenient for different usage;Good Heat dissipation:
4. Using double PCB to increase the conductivity of heat and electricity and decrease the brightness difference caused by voltage drop as well;
5. Long Life span: over 50000 hours,
6. Easy Installation: With 3M self-adhesive tape for easy installation onto any flat surfaces;
7. Safe & Energy Saving: power supply at constant 12V DC; Low voltage is safer and more energy saving and eco-friendly.
8. OEM, ODM, package design and door to door shipment services
Application
1. Archway/canopy and bridge edge
lighting
2. Auditorium walkway lighting
3. Backing lighting for signage letters
4. Stairway accent lighting,DIY lights
for home use
5. Amusement park/theater/aircraft cabin
mood lighting
6. Channel letters lighting
7. Somewhere Need to energy saving and
auxiliary lighting, decorative lighting
